Chess set
por Thorin Oakenshield en Printables
Luxury chess set with a folded chessboard
Licencia
Solo uso personalCC BY-NC-ND 4.0 — Atribución, no comercial, sin derivadas
Solo para uso personal, sin modificarlo y dando crédito. No se permite vender ni redistribuir cambios.
Al descargar aceptas respetar la licencia y dar crédito a Thorin Oakenshield.
Archivos (21)
- King head.stl STL · 2,6 MB
- King body.stl STL · 2,3 MB
- Queen head.stl STL · 2,2 MB
- Queen body.stl STL · 2,2 MB
- Bishop head.stl STL · 1,9 MB
- Bishop body.stl STL · 1,9 MB
- Knight head.stl STL · 1,9 MB
- Knight head new.stl STL · 8,9 MB
- Knight body.stl STL · 1,6 MB
- Rook head.stl STL · 958 KB
- Rook body.stl STL · 2,2 MB
- Pawn head.stl STL · 1,2 MB
- Pawn body.stl STL · 1,6 MB
- Block.stl STL · 9 KB
- Frame 4x.stl STL · 23 KB
- Pawn_0.4n_0.2mm_PLA_MK3S_51m.gcode GCODE · 2,9 MB
- Rook_0.4n_0.2mm_PLA_MK3S_1h10m.gcode GCODE · 4,1 MB
- Bishop_0.4n_0.2mm_PLA_MK3S_1h21m.gcode GCODE · 4,6 MB
- King_0.4n_0.2mm_PLA_MK3S_1h53m.gcode GCODE · 6,5 MB
- Knight_0.4n_0.2mm_PLA_MK3S_1h30m.gcode GCODE · 5,2 MB
- Queen_0.4n_0.2mm_PLA_MK3S_1h33m.gcode GCODE · 5,3 MB
- Categoría
- Juguetes y juegos
- Formatos
- STL, GCODE
- Descargas
- 6,551
- Publicado
Sobre este modelo
Chess set with a foldable chessboard Figures are made of two parts - body and head. Only the horse's head needs supports. Update ! Added new horse head, better modeled, it's not perfect, but if you like it more, you can download it
I uploaded the g-code with my settings - variable layer height - for better printing of overhangs, finer details, 5 perimeters, 40% infill, 10 bottom layers - so that the figures are strong and have weight. also a horse head model with supports If the models with a small surface would come off, especially the heads, use the outline around it. The parts hold well even without gluing Checkerboard - fold the frame and connect the squares, 32 of each color, the last one is the most difficult, but I succeeded. The outer dimensions of the checkerboard are 35,3 x 35,3cm, The size of one playing square is 40x40mm You can make your own size, just increase the parts by the same percentage in all directions
I make all my models for you for free, but if you would like to support me, you can become a member of my club!
Descripción original del autor, publicada en Printables.
