Snap-Fit Test Coupon - Find Your Printer's Perfect Tab & Slot Tolerance (Free)
por Drec666 en Printables
3 tiny parts, ~15 min: find the snap-fit clearance your printer needs. Standard + Loose fits. Free from CritterForge.
Licencia
Solo uso personalStandard Digital File License
Licencia estándar de archivos digitales: solo uso personal. No se permite compartir, revender ni subir el archivo a otros sitios, ni vender las impresiones.
Al descargar aceptas respetar la licencia y dar crédito a Drec666.
Archivos (5)
- Categoría
- Para tu impresora
- Formatos
- STL, TXT
- Descargas
- 1
- Publicado
Sobre este modelo
About 10 minutes of printing tells you the exact tab-and-slot clearance your printer needs, before you commit hours to a big snap-fit build.
WHAT'S INCLUDED - Bar A: slot bar with 5 slots opened by 0.06 / 0.10 / 0.14 / 0.18 / 0.24 mm per side
- - Bar B: matching tab bar
- - Plate C: four crystal seats (about 3.8 / 4.2 / 4.6 / 5.0 mm) for flat-back rhinestones
- - READ_ME_FIRST and license files
HOW TO USE - Print A and B flat with the same filament and settings you'll use for the real model (0.2 mm layers).
- 2. Push the tab into each slot. Pick the tightest one that slides in with light finger pressure and doesn't fall out.
- 3. Best fit 0.10-0.14 mm: use STANDARD files. Best fit 0.18-0.24 mm: use LOOSE files. Everything tight: calibrate flow / XY compensation first.
WHY THIS EXISTS Every CritterForge Gingerbread Village house ships in both Standard and Loose fits. This coupon tells you which one to print so your house snaps together without glue on the first try. Plate C shows which rhinestone size fits the optional bling seats (the houses use 4.2 mm / SS16).
Want the full village? Six original gingerbread houses, Snap-In Christmas Critters and Village Tiles are on my profile. Search "CritterForge".
