Printed Tabletop Band Weaving / Tablet Loom

Attribution: A 3D printed implimentation providing the funtionality of a historical Inkle / Tablet loom Printed Parts Printed from HS-PLA on Creality K1 high speed printer 220x220x250 build area Requires multiple plates 3 wall loops 4 Shell Layers 25% Infill Tubes and drum printed vertical with raft. Drum may also require manual supports to lower octaginal face Notched castle top tube parts printed horizontal on flattened face. Recomend small layer height for threads to print well Risers printed with screw countersinks down, 'rabbit' face up Non-printed parts Base plate is 5/4 x 6 wood board True diminsions 1" x 5.5" Length and material can be adjusted to user choice. Prototype approx 20" long clear Poplar Requires 8x #10 flat top (countersink) x 2" wood screws Requires 2x 1/4-20x2 Carriage Bolts Recommend flat bottom countersink pocket on bottom of base plate Requires 2x 1/4-20 threaded Nylon knobs Requires 1" grip Button Push Pin (flared collar may be used if pindoes not provide adequate finger grip area. Protype used "uxcell Quick Release Pin, 1/4" x 1.06"(Dia. x L) Ball Locking Pin with Push Button" from Amazon Supporting Parts Card holder used during warping, removed during weaving Weight cans for weighted warp, fill with small metal shot. Warp may mix weighted and drum-wrapped threads. Print 3 wall loops, 3 shell layers, 15% infill. Require 1/2 Inch Metal Cup Hooks (Avail Amazon Hulless 100 Pcs 1/2 Inch Metal Cup Hooks) Assembly Recommend dry-fitting risers and cross tubes using bar clamps to locate towers. Once clamped use transfer punches to mark all fastener hole locations for drilling. Holes for cross tubes are tapered to give tolerance on alignment of the towers.
