Iron Man MK6 MK 6 Suit

update 07.01.2018: uploaded sketch for back and helmet.

Here are my files for a complete Iron Man MK6 suit.

It looks great, but it is NOT comfortable.

And because it is halloweentime I added a battledamaged mask for the helmet.

Here is a video of the moving faceplate. Special thanks to "redeathray" for checking my code and helping me.

https://youtu.be/Wdb1UWU4UAY

https://youtu.be/P-KLNkn2KAA

https://youtu.be/ZY1E9p6GItU

The pictures show me trying out all parts.The electronics are not yet completed, but I think you are more interrested in the files.

One picture shows a small version of the MK6 helmet as battledamaged. I gonne use it as decoration for Halloween.

I prefere the MK3 helmet to wear. I like the look more.

You can download it from "jhon De Sousa" on the following link:

http://www.thingiverse.com/thing:260152

Most parts are founded on the following 24cm high Iron Man MK6 shell figure from "RohitVen". I asked him to rework and publish his files as a costume and he agreed to.

http://www.thingiverse.com/thing:1026995

The gloves are made of a Papakura file. The glove is originaly made by "zabana" and remixed by "darkside501st". Below the original link for the glove:

http://www.therpf.com/showthread.php?t=139470&highlight=hand+zabana

As arc reactor I used this Modell from "Thaurus":

http://www.thingiverse.com/thing:1377484

All parts were made for a Prusa I3 with a 220x220x240mm buildplate.

If you have any problems or find parts which are to big please contact me and I will do my best to change it.

Except of the printed parts, some buckles (printed or bought), elastic strap and a lot of soft foam for a little comfort you will need the following parts:

Helm: 4x M4 Bush, MG995 Servo, any arduinoor other micro controller, at least 8x LED white, 4x M4x10, 4x M3x20, 4x M3 nut, acrylglass, 2x contactor , (or 1x, depending on the sketch you use)

Neck: EVA foam for a comfortable and flexible neck (if you want to make a neck)

Chest: acrylglass 2x M4x40, 2x M4 nut,

ABS: EVA foam for a comfortable and flexible sideparts

Lower arm (each): some springs for a backflipping handplate, M4x20, M4 nut

Gloves (each): 4x LED White, 1x G4 COB LED spot, 1x contactor (to enable G4 COB as repulsor)

Hips: M4x25, M4 nut

Thigh: if you want the knee moving / flapping you will need four springs. I used a blow-dryer to make it a Little more comfortable, because they are really to narrow for my legs. But I could not resize them, because then they wont fit to the rest of the costume and it won't look good .
