Forklift truck .STEP
I was looking for an forklift to simulate transport process in my project, but I couldn't find adequate. So, I decided to build one with fully movement funcionality. In load range 10000 to 20000 lb, I was choose CAT DP70 with 15500 lb load capacity.
Thangs entrega los archivos a usuarios con cuenta gratuita
Licencia
Solo uso personalSin licencia indicada
El autor no indicó una licencia: todos los derechos le pertenecen. Úsalo solo para imprimir en casa y consulta al autor para cualquier otro uso.
Al descargar aceptas respetar la licencia y dar crédito a Haktan Y.
Archivos (1)
- GC_CAT DP70.STEP STEP · 20,8 MB
- Categoría
- Varios
- Formatos
- STEP
- Descargas
- 296
- Publicado
Sobre este modelo
I was looking for an forklift to simulate transport process in my project, but I couldn't find adequate. So, I decided to build one with fully movement funcionality. In load range 10000 to 20000 lb, I was choose CAT DP70 with 15500 lb load capacity.
All dimensions in model are taken from CAT official catalogue and their blueprint drawings.
In SW model all movement are conducted with equation manager. In column "comments" are given movement limits values.
