Double Rack - DIY Filament Storage - RepRack Remix!
DIY Doubled Up!
Thangs entrega los archivos a usuarios con cuenta gratuita
Licencia
Solo uso personalCC BY-NC-SA 4.0 — Atribución, no comercial, compartir igual
Uso personal dando crédito; sin fines comerciales y las modificaciones con la misma licencia.
Al descargar aceptas respetar la licencia y dar crédito a Alan M.
Archivos (7)
- Double_Shelf_RepRack_LEFT_V3.stl STL · 823 KB
- Double_Shelf_RepRack_MID_V3.stl STL · 729 KB
- Double_Shelf_RepRack_RIGHT_V3.stl STL · 823 KB
- Double_Shelf_RepRack_V3.step STEP · 5,2 MB
- RepRack_Clamp_HeatPress_V1.stl STL · 197 KB
- RepRack_Clamp_M4_V1.stl STL · 202 KB
- RepRack_Clamp_ThreadCutScrews_V1.stl STL · 219 KB
- Categoría
- Para tu impresora
- Formatos
- STL, STEP
- Descargas (todas las plataformas)
- 859
- Publicado
También en
Sobre este modelo
DIY Doubled Up!
Remixed version of "RepRack" (https://www.printables.com/model/129024-reprack-open-source-spool-holder-and-storage-syste) filament storage system that stacks 2 rows of Filament spools atop of each other. Designed to sit on a shelf or shelving unit. Uses 1/2" EMT conduit as the "Rack rails" of the system. Requires screws to install the clamps that retain the rack rails.
Requires additional hardware: - Thread Cutting Screws - M4 Hardware - M3 Hardware - M3 Heat Press Inserts - 1/2" EMT Conduit
Brackets are sizable and won't fit on an Ender 3 (or similar 235mm) bed. Measures 248mm x 208mm. Sized specifically to fit within a Prusa Mk3 / Mk4 build volume (also fits the Bambu X1 & P1P bed).
--------------------------------------------------------------- Parts Needed (Affiliate Links): - 1/2" Conduit: https://www.lowes.com/pd/Common-1-2-in-Actual-50-In-Metallic-Emt-10-ft-Conduit/3129551 - M3 Heat Inserts: https://amzn.to/3LEMezN - Polymaker Filament: https://tinyurl.com/Polymakerr --------------------------------------------------------------- Files Included: - Double RepRack STEP File - Left Double Rack STL - Right Double Rack STL - Mid Double Rack STL - M4 Clamp STL - Thread Cutting Screw Clamp STL - M3 Insert Clamp STL - Double Rack DXF --------------------------------------------------------------- Recommended Print Settings: - 3+ Perimeters - 20% Infill - No Supports Required - PLA filament is generally fine for this application. If near hot components ASA or ABS would be preferred. - Bigger nozzle sizes & layer heights recommended (.6/.8) but not required. --------------------------------------------------------------- Want to Support what I do? Check out my social medias please!
Link Tree: http://www.MandicReally.com/links
---------------------------------------------------------------
NOTE: Larger diameter spools may not fit. Only ones I know for certain are Printed Solid, their cardboard spools don't fit on the lower rack, but do on the upper. Polymaker & even ProtoPasta spools do fit fine.
Descripción original del autor, publicada en Thangs.
